1SFL607002R1111

The ABB AF370-30-11-11 Contactor, Part No. 1SFL607002R1111, is a heavy-duty 3-phase, 3-pole power contactor designed for high-current industrial motor-control and power-switching applications. It uses ABB’s wide-range electronic AF coil technology with a control voltage of 24–60 V AC, 50/60 Hz, and 20–60 V DC. The contactor is fitted with 3 normally-open main contacts and 1 NO + 1 NC auxiliary contact. For AC-3 motor duty, ABB rates the AF370 at 370 A at 380/400 V, 415 V and 440 V, 315 A at 500 V and 690 V, and 141 A at 1000 V. Its corresponding motor-power ratings are 200 kW at 380/400 V, 415 V and 440 V, 250 kW at 500 V, and 315 kW at 690 V. For AC-1 duty, it can carry up to 600 A at 690 V and 40°C.
