1SBL177001R1201
INR 3353INR 9580
In stock
Description
The ABB AF16-30-01-12, Product ID 1SBL177001R1201, is a compact industrial 3-pole block contactor from ABB’s AF series, developed for reliable switching of three-phase motors and industrial electrical loads. It features 3 normally-open main power contacts and 1 built-in normally-closed auxiliary contact (0 NO + 1 NC).
The contactor uses ABB’s electronic wide-range coil technology, operating from 48–130 V AC at 50/60 Hz and 48–130 V DC.
For AC-3 motor switching, the AF16 family is rated at 18 A at 380/400/415/440 V. Typical motor ratings include 7.5 kW at 400 V and 9 kW at 415/440 V.
Specifications
| Model | AF16-30-01-12 |
|---|---|
| Main Poles | 3 Pole |
