A9HKS532

This Acti9 power socket distribution board comes with reversible single metal door for door opening. This distribution board allows to mount a 5P panel-mounted socket and modular devices with a width of 4 modules of 18mm. The In rated current is 32A. The dimensions are (W) 138mm x (H) 305mm x (D) 65mm. The color of the distribution board is white (RAL 9003). The degree of protection is IP30, IK08 with the single metal door. This distribution board is compliant with IS 8623-1, IS 8623-3 and IEC 61439-3 standards.
