2CSR275075R2324

The ABB DSB201 M AC-C32/0.1, part number 2CSR275075R2324, is a residual current circuit breaker with overcurrent protection (RCBO) designed to provide combined protection against overloads, short circuits and earth-leakage faults in electrical installations.

This device has a rated current of 32 A, a C-type tripping characteristic and a rated residual operating current of 100 mA. It uses AC-type residual-current detection and a 1P+N configuration for compatible single-phase electrical circuits. The compact, two-module design allows installation on a DIN rail in suitable electrical distribution boards and control panels.

The circuit breaker is suitable for residential, commercial and industrial electrical distribution applications where its current rating, leakage sensitivity and breaking capacity meet the system requirements. Installation and selection should be performed by a qualified electrician in accordance with ABB's technical documentation and applicable electrical standards.
