2CSR275075R2064
INR 3245INR 9270
In stock
Description
ABB DSB201 M AC-C6/0.1 is a miniature residual current circuit breaker with integrated overcurrent protection (RCBO). It combines overload protection, short-circuit protection and earth-leakage protection in a single modular device. The product is designed for single-phase electrical distribution systems and DIN-rail mounting.
It has a rated current of 6 A, a C-type tripping characteristic and a rated residual operating current of 100 mA. Its Type AC residual-current detection responds to sinusoidal alternating residual currents.
Specifications
| Rated current | 6 A |
|---|---|
| Rated voltage | 240 V AC |
