2CSR275075R1164

The ABB DSB201 M AC-C16/0.03 is a residual current circuit breaker with integrated overcurrent protection (RCBO), designed to protect single-phase electrical circuits against earth-leakage currents, overloads and short circuits. It combines residual-current protection and miniature circuit-breaker functions in a compact device. With a rated current of 16 A, a residual operating current of 30 mA, a C-curve tripping characteristic and Type AC residual-current detection, it is suitable for compatible single-phase electrical distribution circuits. Its 1P+N configuration and DIN-rail mounting make it suitable for installation in electrical distribution boards.
