1SYS274012R0024

The ABB SB204M-C2 miniature circuit breaker is a current-limiting electrical protection device designed to protect compatible low-voltage circuits against overloads and short circuits. It features four poles, a rated current of 2 A, and a C-curve tripping characteristic.

The device uses a delayed thermal tripping mechanism for overload protection and an electromagnetic tripping mechanism for short-circuit protection. With a rated voltage of 415 V AC and a rated short-circuit breaking capacity of 10 kA, it is intended for suitable residential, commercial and industrial electrical distribution applications. The SB200M product range complies with IS/IEC 60898-1.
