1SDA116346R1

Reliable Circuit Protection: ABB SACE Formula series MCCB designed for overload and short-circuit protection in AC and DC systems.

High Breaking Capacity: “P2N” standard breaking capacity variant (refer to label for kA ratings).

4-Pole with Fully Rated Neutral: Features a 4th pole capable of carrying 100% of the rated phase current (InN=100%), ideal for harmonic-rich environments.

Adjustable TMD Trip Unit: Thermomagnetic release (TMD) with adjustable thermal setting (Ir: 0.7...1 x In) and fixed magnetic setting (Ii: 10 x In).

Rated Current: 250 A

Durable & Efficient: High mechanical durability (20,000 cycles) and low power loss (17.80 W per pole).

Fixed Design: Features fixed front terminals (F F) for secure and permanent installation.

Certified Quality: Product ID 1SDA116346R1, EAN 8056221084543, CE marked, and fully compliant with international IEC standards.
