1SDA116236R1

The ABB P1C 160 TMD 125-1250 3P F F is a high-performance 3-pole fixed Moulded Case Circuit Breaker (MCCB) designed for reliable protection of electrical distribution circuits against overload and short-circuit conditions.

It features a thermomagnetic TMD release, front terminal connections, and a 160 A frame size with a 125 A rated current. The adjustable protection setting range is 87.5–125 A, allowing the breaker to be appropriately configured for the connected electrical load.

With a 500 V AC rated operational voltage, 750 V insulation voltage, 8 kV impulse withstand voltage, and 40 kA service short-circuit breaking capacity at 240 V AC, this MCCB is suitable for industrial, commercial and low-voltage power distribution applications.
