1SDA107565R1

ABB SACE Tmax XT6N 800 Ekip M Dip I Circuit Breaker (630A, 3-Pole, Motor Protection)

Ensure precise short-circuit protection for your largest motor circuits with the ABB SACE Tmax XT6N 800 Ekip M Dip I. This heavy-duty 3-pole Molded Case Circuit Breaker (MCCB) is rated at 630A and features an Ekip M Dip I electronic trip unit, providing instantaneous (short-circuit) protection only—ideal for motor protection applications where overload protection is handled separately.

Unlike standard breakers, the Ekip M Dip I trip unit focuses purely on magnetic (short-circuit) protection, allowing for precise coordination with separate thermal overload relays in motor starter assemblies. This makes it an ideal choice for protecting large motors and distribution feeders in the most demanding industrial environments.

Built on the massive XT6N 800 frame, this breaker provides a high breaking capacity and features a loose or configurable design for flexible installation. It offers excellent versatility with a rated operational voltage of up to 690V AC, making it a reliable choice for modern power distribution systems.

Engineered for longevity, it delivers a mechanical lifespan of 20,000 cycles and an electrical lifespan of 5,000 cycles. With front bolt terminals, installation is secure, straightforward, and built for high-current applications. The 3-pole configuration is ideal for standard three-phase loads
