1SDA100013R1

ABB SACE Tmax XT2N 160 molded case circuit breaker (MCCB), fixed three-pole configuration with front terminals and Ekip DIP LIG electronic solid-state release, rated at 100 A. It is designed for low-voltage AC power distribution and provides protection against overload, instantaneous short circuit and earth-fault conditions. The breaker uses a 160 A frame and has a 690 V AC rated operational voltage, 1000 V insulation voltage and 8 kV impulse withstand voltage. Its N version provides 36 kA service short-circuit breaking capacity at 380–440 V AC, making it suitable for industrial, commercial and distribution-panel applications.
