1SDA080835R1

ABB SACE Tmax XT1H 160 3-Pole Molded Case Circuit Breaker (16A - 450A)

Ensure precise protection for your equipment with the ABB SACE Tmax XT1H 160. This 3-pole Molded Case Circuit Breaker (MCCB) is rated at 16A and features a highly reliable thermomagnetic release (TMF) for precise overload and short-circuit protection, with a fixed magnetic trip at 450A.

Built on the robust XT1H frame, this breaker provides a high breaking capacity for standard commercial and light industrial power distribution systems. It offers excellent versatility with a rated operational voltage of up to 690V AC, making it an ideal choice for protecting control circuits, small motors, and sensitive sub-distribution panels where high inrush currents are expected.

Engineered for longevity, it delivers a mechanical lifespan of 25,000 cycles and an electrical lifespan of 8,000 cycles. With front bolt terminals, installation is secure, straightforward, and space-efficient. The 3-pole configuration is ideal for standard three-phase loads.
