1SDA068364R1

ABB SACE Tmax XT4H 250 molded case circuit breaker (MCCB), fixed four-pole configuration with front terminals and TMA R 250 thermomagnetic release. The circuit breaker has a rated current of 250 A and provides adjustable thermal overload protection with a setting range of 175–250 A. The instantaneous magnetic short-circuit protection (I3) is adjustable from 1250 to 2500 A. The breaker features a fully rated neutral (100%), high short-circuit breaking capability and is designed for reliable protection and control of low-voltage electrical distribution systems.
