1SDA068281R1

ABB SACE Tmax XT3S 250 moulded-case circuit breaker (MCCB), rated 160 A, 3-pole, fixed execution with front terminals and adjustable magnetic MA release. The instantaneous magnetic trip setting is adjustable from 960 A to 1920 A. It is designed for low-voltage circuit protection, particularly for motor protection applications. The XT3S S-class breaker provides a 50 kA short-circuit performance level at 380/415 V AC and is rated for operation up to 690 V AC / 500 V DC.
