1SDA068121R1

ABB SACE Tmax XT4N 250 moulded-case circuit breaker (MCCB), rated 200 A, 3-pole, fixed execution with front terminals and MA magnetic release. The instantaneous magnetic trip setting is adjustable from 1000 A to 2000 A. It is designed for low-voltage circuit protection, including motor and power-distribution applications. The breaker has a 690 V AC rated operational voltage, 1000 V insulation voltage, and 36 kA service short-circuit breaking capacity at 380–440 V AC.
