1SDA068073R1

ABB SACE Tmax XT3N 250 moulded-case circuit breaker (MCCB), rated 160 A, 3-pole, fixed execution with front terminals and adjustable magnetic MA release. The instantaneous magnetic trip setting is adjustable from 960 A to 1920 A. It is designed for low-voltage circuit protection and applications such as motor, transformer, generator, and installation protection. The breaker has a 690 V AC rated voltage, 500 V DC operational voltage, and 36 kA short-circuit performance level.
