1SDA067892R1

ABB SACE Tmax XT2H 160 4-Pole Molded Case Circuit Breaker (63A, Electronic Ekip Dip LS/I)

Achieve advanced protection and coordination for your equipment with the ABB SACE Tmax XT2H 160. This 4-pole Molded Case Circuit Breaker (MCCB) features a state-of-the-art electronic trip unit (Ekip Dip LS/I), rated at 63A, providing precise overload (L), short-time (S), and instantaneous (I) protection in a single device.

Unlike standard thermomagnetic breakers, the Ekip Dip electronic trip unit allows for precise digital calibration of protection settings, eliminating nuisance tripping and ensuring optimal coordination with downstream devices. This makes it an ideal choice for protecting main feeders, sub-distribution panels, and large motors in demanding commercial and industrial environments.

Built on the robust XT2H frame, this breaker provides a high breaking capacity with an 100 kA service breaking capacity (Ics) at 220/230/240 V AC. It offers excellent versatility with a rated operational voltage of up to 690V AC, making it a reliable choice for modern power distribution systems.

Engineered for longevity, it delivers a mechanical lifespan of 25,000 cycles and an electrical lifespan of 8,000 cycles. With front bolt terminals designed for busbars 32.5 to 100 mm², installation is secure, straightforward, and space-efficient. The 4-pole configuration ensures full protection for both phase and neutral lines.

Key Features:
