1SDA067865R1

ABB Tmax XT2H 160 Ekip I, 100 A, 3-pole, fixed MCCB (moulded-case circuit breaker), front terminals. ABB documentation identifies the ordering code as 1SDA067865R1. BREAKER TMAX XT2H 160 FIXED THREE-POLE WITH FRONT TERMINALS AND SOLID-STATE RELEASE IN AC EKIP-I R 100 A. 100 A rated current, 3 poles, up to 690 VAC/VDC rated voltage, 70 kA breaking capacity, Ekip-I electronic/solid-state release, front connection, IEC 60947-2. Designed for low-voltage electrical distribution and circuit protection applications, providing reliable switching and overcurrent protection in industrial and commercial installations.
