1SDA067779R1

ABB SACE Tmax XT2H 160 moulded-case circuit breaker (MCCB), rated 100 A, 3-pole, fixed execution with front terminals and MA magnetic release. The breaker features an adjustable instantaneous magnetic trip range of 600–1400 A and is designed to provide reliable short-circuit protection for low-voltage electrical installations, including power distribution, cables, generators, transformers and motor circuits. The XT2H high-breaking-capacity version provides up to 70 kA rated service short-circuit breaking capacity at 380/415 V AC. It is suitable for systems with a rated operational voltage up to 690 V AC / 500 V DC, with 1000 V insulation voltage and 8 kV impulse withstand voltage. ABB identifies this exact configuration as XT2H 160 MA 100 Im=600...1400 3P F F.
