1SDA067775R1

ABB SACE Tmax XT2H 160 moulded-case circuit breaker (MCCB), rated 20 A, 3-pole, fixed execution with front terminals and magnetic MA release. The breaker features an adjustable instantaneous magnetic short-circuit trip range of 120–280 A. It is designed for protection of low-voltage electrical systems, including power distribution, cables, generators and motors. The XT2H high-breaking-capacity version provides up to 70 kA service short-circuit breaking capacity at 380/415 V AC. It is suitable for applications up to 690 V AC / 500 V DC, with a 1000 V insulation voltage and 8 kV impulse withstand voltage.
