1SDA067772R1

ABB SACE Tmax XT2H 160 moulded-case circuit breaker (MCCB), rated 4 A, 3-pole, fixed execution with front terminals and MF magnetic release. The breaker has a fixed instantaneous magnetic trip setting of 56 A (14 × In) and is designed for protection of low-voltage motor circuits and electrical installations. The XT2H high-breaking-capacity version provides up to 70 kA short-circuit breaking capacity at 380/415 V AC, with a rated operational voltage of 690 V AC / 500 V DC and rated insulation voltage of 1000 V.
