1SDA067770R1

ABB SACE Tmax XT2H 160 moulded-case circuit breaker (MCCB), rated 1 A, 3-pole, fixed execution with front terminals and MF magnetic release. The breaker features a fixed magnetic trip setting of 14 A (14 × In) and is designed for reliable protection of low-voltage motor circuits and electrical installations. With its XT2H high-breaking-capacity design, the breaker provides high short-circuit protection, with an ultimate breaking capacity of up to 70 kA at 380/415 V AC. It is suitable for systems with a rated operational voltage up to 690 V AC / 500 V DC and a rated insulation voltage of 1000 V. The compact fixed construction and front-terminal configuration make it suitable for installation in industrial control panels, motor control centers and low-voltage distribution systems.
