1SDA067598R1

ABB SACE Tmax XT2H 160 3-Pole Molded Case Circuit Breaker (40A)

Achieve ultimate flexibility and robust fault protection with the ABB SACE Tmax XT2H 160. This high-performance 3-pole Molded Case Circuit Breaker (MCCB) features an adjustable thermomagnetic release (TMA) rated at 40A, allowing you to precisely calibrate your protection to match specific load requirements.

Unlike standard breakers, this unit offers an adjustable instantaneous short-circuit setting (300A - 400A), allowing you to fine-tune the magnetic trip to prevent nuisance tripping from motor inrush currents while maintaining high safety standards.

Built on the robust XT2H frame, it offers an exceptional 70 kA breaking capacity at 415V AC, ensuring robust protection against severe short circuits. It provides excellent versatility with a rated operational voltage of up to 690V AC and 500V DC, making it an ideal choice for protecting motors, control transformers, and sub-distribution feeders in demanding industrial and commercial environments.

Engineered for longevity, it delivers a mechanical lifespan of 25,000 cycles and an electrical lifespan of 8,000 cycles. With front bolt terminals designed for busbars ranging from 32.5 to 100 mm², installation is secure, straightforward, and space-efficient.
