1SDA067597R1

ABB SACE Tmax XT2H 160 3-Pole Molded Case Circuit Breaker (32A)

Ensure ultimate safety for your equipment with the ABB SACE Tmax XT2H 160. This high-performance 3-pole Molded Case Circuit Breaker (MCCB) is rated at 32A and features a highly reliable thermomagnetic release (TMD) for precise overload and short-circuit protection.

Built on the robust XT2H frame, this breaker is specifically engineered for installations with very high prospective short-circuit currents, offering an exceptional 70 kA breaking capacity at 415V AC. It provides excellent versatility with a rated operational voltage of up to 690V AC and 500V DC, making it an ideal choice for protecting motors, sub-distribution feeders, and control transformers in demanding industrial and commercial environments.

Engineered for longevity, it delivers a mechanical lifespan of 25,000 cycles and an electrical lifespan of 8,000 cycles. With front bolt terminals designed for busbars ranging from 32.5 to 100 mm², installation is secure, straightforward, and space-efficient.
