1SDA067596R1

ABB SACE Tmax XT2H 160 3-Pole Molded Case Circuit Breaker (25A)

Achieve flexible protection with superior fault tolerance using the ABB SACE Tmax XT2H 160. This 3-pole Molded Case Circuit Breaker (MCCB) features an adjustable thermomagnetic release (TMD) set to a base rating of 25A, allowing precise tuning to match your specific low-load industrial equipment while offering a robust short-circuit trip at 300A.

Built on the high-performance XT2H frame, this breaker is specifically engineered for installations with very high prospective short-circuit currents. It offers an exceptional 70 kA breaking capacity at 415V AC, ensuring your machinery and panel remain completely safe even during severe fault conditions. The breaker provides excellent versatility with a rated operational voltage of up to 690V AC and 500V DC, making it an ideal choice for protecting motors, control transformers, and sub-distribution feeders in demanding industrial environments.

Engineered for longevity, it delivers a mechanical lifespan of 25,000 cycles and an electrical lifespan of 8,000 cycles. With front bolt terminals designed for busbars ranging from 32.5 to 100 mm², installation is secure, straightforward, and space-efficient.
