1SDA067590R1

ABB SACE Tmax XT2H 160 3-Pole Molded Case Circuit Breaker (6.3A - 63A)

Achieve precise and robust protection for your three-phase equipment with the ABB SACE Tmax XT2H 160. This high-performance 3-pole Molded Case Circuit Breaker (MCCB) features an adjustable thermomagnetic release (TMD), allowing you to set the overload protection range between 6.3A and 63A to perfectly match your load requirements.

Built on the robust XT2H frame, this breaker is specifically engineered for installations with high fault currents, offering an exceptional 70 kA breaking capacity at 415V AC. It provides excellent versatility with a rated operational voltage of up to 690V AC and 500V DC, making it an ideal choice for protecting motors, transformers, and sub-distribution feeders in demanding industrial and commercial environments.

Engineered for longevity, it delivers a mechanical lifespan of 25,000 cycles and an electrical lifespan of 8,000 cycles. With front bolt terminals designed for busbars ranging from 32.5 to 100 mm², installation is secure, straightforward, and space-efficient.
