1SDA067555R1

ABB SACE Tmax XT2S 160 moulded-case circuit breaker (MCCB), fixed three-pole configuration with front terminals and thermomagnetic adjustable TMA release. The breaker has a rated current of 50 A and an adjustable overload protection setting range of 35–50 A. Its instantaneous short-circuit release is adjustable from 250–500 A. Designed for low-voltage electrical distribution and industrial applications, the XT2S 160 provides dependable protection against overloads and short circuits. The breaker has a 160 A frame rating, rated operational voltage up to 690 V AC / 500 V DC, rated insulation voltage of 1000 V and impulse withstand voltage of 8 kV. At 380/415/440 V AC, it provides 50 kA service short-circuit breaking capacity and complies with IEC standards.
