1SDA067553R1

ABB SACE Tmax XT2S 160 moulded-case circuit breaker (MCCB), fixed three-pole configuration with front terminals and thermomagnetic TMD release, rated current 32 A. The circuit breaker is designed to provide reliable overload and short-circuit protection in low-voltage electrical distribution and industrial applications. It features a 160 A frame size, an adjustable thermal overload setting range of 22.4–32 A and a magnetic release setting of 320 A. The breaker is rated for operation up to 690 V AC / 500 V DC, with 1000 V insulation voltage and 8 kV impulse withstand voltage. The XT2S version provides up to 50 kA service short-circuit breaking capacity at 380–440 V AC and complies with IEC standards.
