1SDA067550R1

ABB SACE Tmax XT2S 160 moulded-case circuit breaker (MCCB), fixed three-pole configuration with front terminals and thermomagnetic TMD release, rated current 16 A. The circuit breaker is designed for overload and short-circuit protection in low-voltage power distribution applications. It has a 160 A frame size, rated operational voltage up to 690 V AC, rated insulation voltage of 1000 V and rated impulse withstand voltage of 8 kV. The XT2S version provides a service short-circuit breaking capacity of 85 kA at 220–240 V AC, 50 kA at 380–440 V AC, 36 kA at 500 V AC and 12 kA at 690 V AC. The device is fixed-mounted, uses front terminals, has Category A selectivity and complies with IEC standards.
