1SDA067549R1

ABB SACE Tmax XT2S 160 moulded-case circuit breaker (MCCB), fixed three-pole configuration with front terminals and thermomagnetic TMD release, rated current 12.5 A, with an adjustable thermal protection setting range of 8.75–12.5 A and a magnetic short-circuit release setting of 125 A. The breaker features a 160 A frame size and is designed to provide reliable overload and short-circuit protection in low-voltage electrical distribution and industrial applications. It has a rated operational voltage of up to 690 V AC / 500 V DC, rated insulation voltage of 1000 V and rated impulse withstand voltage of 8 kV. The XT2S version provides a service short-circuit breaking capacity of up to 50 kA at 380–440 V AC and complies with IEC standards.
