1SDA067548R1

ABB SACE Tmax XT2S 160 moulded-case circuit breaker (MCCB), fixed three-pole configuration with front terminals and thermomagnetic TMD release, rated current 10 A, with an adjustable overload protection setting range of 7–10 A and a 100 A instantaneous short-circuit release. The breaker has a 160 A frame size and is designed for reliable overload and short-circuit protection in low-voltage electrical distribution and industrial applications. It features a rated operational voltage up to 690 V AC / 500 V DC, rated insulation voltage of 1000 V and 8 kV impulse withstand voltage. The XT2S version provides a service short-circuit breaking capacity of up to 50 kA at 380–440 V AC and complies with IEC standards.
