1SDA067547R1

ABB SACE Tmax XT2S 160 moulded-case circuit breaker (MCCB), fixed three-pole configuration with front terminals and thermomagnetic TMD release, rated current 8 A, with an adjustable thermal protection setting range of 5.6–8 A and an instantaneous magnetic release corresponding to the 80 A TMD designation. The breaker has a 160 A frame size and S-class short-circuit performance, providing reliable overload and short-circuit protection for low-voltage electrical distribution and industrial applications. It is rated for operation up to 690 V AC and complies with IEC standards.
