1SDA067545R1

ABB SACE Tmax XT2S 160 moulded-case circuit breaker (MCCB), fixed three-pole configuration with front terminals and thermomagnetic TMD release, rated current 5 A, with an adjustable overload-release setting of 3.5–5 A and instantaneous short-circuit release set at 50 A. The breaker has a 160 A frame rating and is designed to provide reliable overload and short-circuit protection in low-voltage electrical distribution and industrial applications. It has a rated voltage range of 220–690 V and a rated short-circuit breaking capacity of 50 kA at 400 V AC. The device uses front bolt connections and is supplied as a complete protection unit.
