1SDA067543R1

ABB SACE Tmax XT2S 160 moulded-case circuit breaker, fixed three-pole configuration with front terminals and thermomagnetic TMD release, rated current 3.2 A, with an adjustable overload protection range of 2.24–3.2 A and instantaneous magnetic short-circuit release set at 32 A. The breaker has a 160 A frame rating, S-class short-circuit performance, rated operational voltage up to 690 V AC / 500 V DC, and provides reliable overload and short-circuit protection for low-voltage power distribution applications. It is manufactured in accordance with IEC 60947-2 standards.
