1SDA067542R1

ABB SACE Tmax XT2S 160 moulded-case circuit breaker (MCCB), fixed three-pole configuration with front terminals and thermomagnetic TMD release, rated current 2.5 A, with adjustable overload protection from 1.75 to 2.5 A and instantaneous short-circuit release at 25 A. The breaker has a 160 A frame size, S (50 kA) breaking-capacity class, rated voltage up to 690 V AC, and is designed for reliable overload and short-circuit protection in low-voltage electrical distribution and industrial applications. It complies with IEC 60947-2 standards.
