1SDA067410R1

ABB SACE Tmax XT1C 160 4-Pole Molded Case Circuit Breaker (160A, Fully Rated Neutral)

Ensure maximum reliability for your high-demand power distribution systems with the ABB SACE Tmax XT1C 160. This top-tier 4-pole Molded Case Circuit Breaker (MCCB) is rated at the maximum frame current of 160A and features a thermomagnetic release (TMD) for robust protection against overloads and short circuits.

Engineered with a Fully Rated Neutral (InN=100%), this breaker ensures the neutral pole provides complete, equal protection to the phase poles. This makes it the ideal choice for systems with severe non-linear loads, harmonics, or high neutral currents.

With a breaking capacity of 25 kA at 415V AC, it delivers superior fault protection. It operates safely across a wide range of voltages (up to 690V AC / 500V DC), making it exceptionally versatile. Its fixed mounting design with front terminals ensures secure integration onto 45.5 to 80 mm² busbars. Built for longevity, it offers an impressive mechanical lifespan of 25,000 cycles and an electrical lifespan of 8,000 cycles.
