1SDA067399R1

ABB SACE Tmax XT1C 160 3-Pole Molded Case Circuit Breaker (160A)

Ensure reliable power distribution and ultimate system protection with the ABB SACE Tmax XT1C 160. This 3-pole Molded Case Circuit Breaker (MCCB) operates at the maximum frame rating of 160A and utilizes a highly efficient thermomagnetic release (TMD) to safeguard your equipment against dangerous overloads and short circuits.

Designed for standard three-phase industrial and commercial applications, it features a fixed instantaneous short-circuit setting of 1600 A, ensuring rapid disconnection during fault conditions. The breaker is built on a robust platform, delivering a rated breaking capacity of 25 kA at 415V AC, making it a reliable choice for switchboards and distribution panels.

Engineered for longevity in demanding environments, it offers a mechanical lifespan of 25,000 cycles and an electrical lifespan of 8,000 cycles. With front bolt terminals designed for busbars ranging from 45.5 to 80 mm², installation is secure and straightforward.
